Full Description
- Moisture Proof Design
- Shallow depth requirement – all models are less than 84 mm deep
- Q Install ceiling speakers utilize ‘UL94’ flame retardant materials
- Q Install speakers come carefully packaged with installation template and fitting instructions
- Perfect for in home or commercial applications
- Excellent for cost effective high quantity installs
Easy To Install
A cutter guide is supplied to mark out the hole you need to make. The speakers then attach to your ceiling via four clamps you screw from the front.
| Tweeter | Swivel |
|---|---|
| Tweeter diameter | 0.75″ (19mm) |
| Woofer diameter | 6.5″ |
| Power handling (program) | 15-60W |
| Impedance (nominal) ohms | 8 |
| Sensitivity dB spl (2.83V, 1m | 89 |
| Response (Low frequency) -3 dB Hz | 75 |
| Maximum rear depth | 79mm |
| Size: (round grille) | 232mm dia |
| Cutout Size | 203mm |
| Warranty | 5 Years |
