Name: Monitor Audio Radius 200 Centre Speaker (Single), Walnut
SKU: YXYUY 49976
Availability: InStock

Comments from customers who bought this item:

Full Description

The Radius 200 centre-channel speaker is designed for rack or shelf mounting in a dedicated home theatre system and room. The driver configuration mirrors that of the 225, and so the 200 has the pedigree and fire-power to capture the detailed dynamics and vocal textures of today’s high definition movie soundtracks. Placed front and centre in a serious AV system, the still compact Radius 200 will anchor the entire sound field with life-like fidelity.

4″ C-CAM bass drivers

In MTM style configuration – Radius features all new bass drivers with concave cone profiles, introduced by our top-of-the-range Platinum speakers and applied subsequently to Gold GX. Extensive research and FEA modelling have allowed us to perfect the relationship between the new radiating diaphragm and its motor design, introducing larger motor sizes and voice coils for increased excursion, higher power capability and reduced distortion.

C-CAM gold dome tweeter

Optimised to deliver the finest and widest performance within the compact Radius cabinets. It benefits from a more efficient rear-venting design, releasing air trapped and compressed at the back of the tweeter dome, and guiding it around the drive assembly to a rear-loading chamber.

HiVe II port design

Straight from Platinum’s design blueprint, the HiVe reflex port makes its Radius debut. It’s shaped to have the same effect on airflow as a gun-barrel on a bullet. Rifled grooves inside the port help to accelerate the flow and reduce turbulence, so air moves in and out of the port more efficiently, for a faster more dynamic bass response.

Single through-bolt driver fixing

Provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.

Frequency Response	60Hz – 35KHz
Sensitivity	86dB
Nominal Impedance	6 ohms
Power Handling Single (RMS)	100 watts
System Power Handling (RMS)	150 watts
Recommended Amplifier Requirements	40-150 watts
Maximum SPL (dBA)	106
Bass Alignment	Bass reflex – rear ported
Driver complement	2 x 4″ (100mm) C-CAM cone bass/mid driver 1 x 1″ (25mm) C-CAM gold dome tweeter
Cabinet Dimensions (H x W x D)	125 x 330 x 140mm (415/16 x 13 x 51/2 Inches)
Cabinet Dimensions (H x W x D) (Inc Grille & Terminals)	125 x 330 x 164mm (415/16 x 13 x 67/16 Inches)
Weight	3.6kg (7lb 14oz)
