Full Description
At only 80mm (3 1/8 inches) diameter, Monitor Audio’s CPC120 is a loudspeaker that offers extraordinary sound quality for a truly innovative application. Its precision engineered micro-design allows it to offer a surprisingly coherent and detailed performance from a standard halogen down-lighter hole.
The secret to the design’s success is that in spite of its size, and unlike many other in-ceiling speakers, it provides a dedicated rigid and mineral-filled enclosure for the driver, giving improved quality and consistency to midrange and bass frequencies wherever the CPC120 is installed.
Although miniaturised, the CPC120’s driver utilises technologies found across Monitor Audio’s more conventional up-market speakers, allowing the CPC120 to blend sonically with Monitor Audio systems of floor, stand, in-ceiling and in-wall speakers for a perfectly-optimised sound anywhere in the home.
Available in brushed steel, white, chrome and brass, the miraculous CPC120 ceiling speaker will also integrate seamlessly with any décor, providing great sound and a liberating wire-free look simultaneously. By utilising conventional fitment clips, installation couldn’t be quicker or simpler.
- Quick and easy discreet flush-fitment to walls or ceilings.
- CP (Controlled Performance) rear enclosures for improved sonic consistency regardless of interior wall or ceiling construction.
- Conventional fitment clips offer quick and simple installation.
Controlled Performance
All Monitor Audio Controlled Performance in-ceiling/wall loudspeakers feature integral CP back boxes. These rigid, mineral-filled enclosures provide an ideal air load for the drivers, optimising midrange and bass performance while maintaining sonic consistency regardless of interior wall construction. The back box also retains the bass driver’s backwave, limiting the transmission of sound to adjacent rooms.
| Frequency Response | 100 Hz – 20 KHz |
|---|---|
| Impedance (Nominal) | 8 Ohms |
| Sensitivity (1W@1M) | 85 dB |
| Maximum SPL | 101.9 dBA |
| Recommended Crossover frequency | 200 Hz |
| Power Handling | 20 W
50 W (using crossover) |
| Recommended Amp Requirements | 5 – 20 W
5 – 50 W (using crossover) |
| Drive Unit Complement | 1x 2″ Full range micro-driver |
| Overall Diameter | 80 mm
(3 1/8 inch) |
| Overall Depth | 96 mm
(3 3/4 inch) |
| Cut-Out Hole Diameter | 65 mm
(2 1/2 inch) |
| Mounting Depth | 91.5 mm
(3 5/8 inch) |
| Fixing Type | 2 x Spring clip fixings |
| Connection | Gold plated “push” type terminals |
| Construction Materials | Steel Bezel
Aluminium Enclosure |
| Weight | 0.19 Kg
(0.42 lb) |
