Full Description
| Frequency Response | 50 Hz – 25 kHz |
|---|---|
| Nominal Impedance | 6 ohms |
| Sensitivity (1W@1M) | 90 dB |
| Maximum SPL (single unit in free space) | 111.6 dBA |
| Power Handling (RMS) | 120 W |
| Recommended Amp Requirements | 30 – 120 W |
| Drive Unit Complement | 1 x 8” MMP II cone bass driver
1 x 1” C-CAM pivoting Gold Dome tweeter |
| Adjustment Controls | HF Level Switch (+3 dB / 0 dB / -3 dB) |
| Overall Diameter: (including grille) | 285 mm (11 1/4″) |
| Overall Depth: (including grille) | 125 mm (4 15/16″) |
| Mounting Depth | 121 mm (4 3/4″) |
| Cut-Out Hole Diameter | 247 mm (9 3/4″) |
| Fixing Type | 3 position Tri-Grip dog fixings |
| Cable Connection | Gold plated ‘push’ type terminals |
| Grille Attachment | Magnetic |
| Construction Material | Mineral filled ABS, RoHS compliant |
| Weight | 2.72 kg (6 lb) |
| Pre-Construction Bracket | CB8 (Green) |
