HELM Audio BOLT DAC/AMP

Full Description

Features

• Studio quality sound from a THX certified DAC
• LED indicators show current sample rate playback
• Blue for idle or SD audio <= 48kHz, Red for HD audio >48kHz, Magenta for MQA content
• Supports files from MP3 right up to MQA for hi-res audio
• Plug and play design keeps operation simple
• Works with Android, iOS, MacOS and Windows 10+ operating systems
• Ultra-Low Harmonic Crosstalk & Reduced Crossover Distortion
• Exclusive 3 Oscillator Design & Impedance Matching
• USB-C Input and 3.5mm Headphone Output

Output Level	1.1Vrms at <150 Ohms, 2Vrms at >150 Ohms
Compatible Formats	PCM, MQA, DSD Dop
Connectivity	USB-C input, 3.5mm Output
SNR	120dB
THD+N	0.0008 at <150 Ohms, 0.0013 at >150 Ohms
Frequency response	20Hz-20kHz &plusmns;0.06dB
Dimensions	Length 112mm
Width	12.8mm
Weight	7.09 grams
Physical	USB Type-C interface
Connection	USB 2.0 High Speed
PCM sample rates	44.1 kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz
Product code	HMQA-100B
