Full Description
“The extra ‘i’ appears to have brought extra sonic maturity with it, making its predecessor sound comparatively crude and less detailed by comparison. The 3010is demonstrate greater clarity and refinement, and prise open the soundstage that bit wider so instruments can site themselves more securely on it.”
The 3000i Series
The Q Acoustics 3000i range improves upon its predecessor, the 3000 range. New features of the 3000i range include an expanded colour selection (you can now choose from Arctic White, Carbon Black, Graphite Grey, and English Walnut), a smaller terminal mounting panel, extra-low-profile binding posts, and larger cabinet volume. Such changes provide both cosmetic and sonic enhancements to the new and improved 3000i speaker series. Expect authentic Hi-Fi experiences with the 3000i speakers, whether you’re enjoying music, cinema, or games.
Mounting Options
The Q Acoustics Q 3020i speaker pair can be mounted on a bookshelf, cabinet or another flat surface with the supplied rubber feet for added support and stability. If you would rather raise your speakers to ear level with dedicated Q Acoustics speaker stands, these can be purchased separately. Alternatively, purchase dedicated wall brackets which will both tilt and turn for flexible positioning on your wall. Stand mounts and wall brackets are available in sizes custom-made for the 3020i bookshelf speakers.
Point-to-Point Bracing
Q Acoustics Point to Point (P2P™) bracing concerns the placement of supportive bracing within the speaker enclosure. This bracing helps keep the internal resonance to a minimum for distraction-free listening. P2P bracing in the 3000i series has been added with the help of computers. This ultra-accurate method eliminates human error and therefore, reduces inconsistencies between speakers. Place your speakers on their rubber feet and enjoy bass without disruptive distortion or cabinet vibration.
Mid/Bass Driver
Within the 3000i range, each speaker features a precision-formed mid/bass driver comprising a coated paper cone, fabric suspension, ultra-stiff pressed steel bracket, voice coil, and motor system. These parts work together to achieve an ideal combination of stiffness, self-damping, and low hysteresis. These are constructed to further eliminate resonance between any components.
High-Frequency Driver
Tweeters within the 3000i series are similarly constructed for limited interference. They comprise an efficient motor system, 22 mm soft ring dome, silicone suspension system, steel stabilising rim, horn profile, and outer rim. The suspension system keeps vibration minimal and isolated for optimal performance.
Excellent Audio
The Denon PMA-600NE integrated stereo amplifier offers 45 Watts of power to each of the two driven channels (8 ohms). The built-in DAC produces hi-res sound quality that’s sure to get the most out of your music. The Advanced High Current (AHC) Single-Push-Pull Circuit provides a clean and clear electrical current supply for minimal distortion or noise in the process of delivering your music.
Awesome Connectivity
Connect to all smart devices thanks to Bluetooth and stream all the best playlists and podcasts on Spotify, TIDAL, and more. The Denon PMA-600NE is equi[pped with two Optical inputs and one Coaxial input that let you connect to your TV, Blu-ray players and support PCM signals up to 192kHz/24-bit. The Analogue Mode even lets you operate the PMA-600NE as a purely analogue amp and disables the digital inputs and Bluetooth to allow for a pure analogue sound. You can also enjoy a frequency response of up to 100 kHz.
Expert Design
Harnessed with a Signal Level Divided Construction (SLDC) chassis, the Denon PMA-600NE has extreme longevity and will fit alongside other Denon products with ease. The Phono equaliser is on hand to make sure you get the best sound from any audio device with a MM cartridge, perfect for creating a divine vinyl sound.
Key Features
- 70 Watts per channel power output (4ohm, 1kHz, THD: 0.7 ) produces strong audio signals
- Advanced High Current (AHC) single-push-pull circuit generates a brilliant sound
- Bluetooth enables wireless connectivity to your smart devices and lets your stream all your music from the best streaming platforms.
- Two digital Optical inputs and one Coaxial input allows for connectivity to your TV and media players
- Built-in 192kHz/24bit D/A converter offers hi-res sounds
- Analogue Mode allows for a pure analogue sound
- High-performance MM phono equalizer lets you get the most out of your vinyl.
What’s in the box?
- 1 x PMA-600NE amplifier
- 1 x Remote control
- 2 x AAA batteries
- 1 x Quick start guide
Specifications
General
| Rated Power | 45W + 45W (8ohm, 20Hz-20kHz, THD 0.07)
70W + 70W (4ohm, 1kHz., THD 0.7 ) |
|---|---|
| Total Harmonic Distortion | .01 (Rated Output –3dB) 8ohm 1kHz |
| Input Sensitivity MM | 2.5 mV / 47 kohm |
| SN Ratio MM | 84 dB (5mV Inputs Signal) |
| CD/Network/Aux/Recorder | 100 mV |
| Input Sensitivity | 110 mV / 30 kohms |
| S/N Ratio | 105 dB |
| Tone Controls | Balance
Bass
Treble |
| Inputs | Phono (MM)
CD
Aux
Optical Inputs x 2
Coaxial Input
Recorder (Playback)
Bluetooth |
| Outputs | Speaker Terminal Pair
Subwoofer Pre-Out
Recorder Out
|
| Power Supply | AC 230V, 50kHz |
| Power Consumption | 185W |
| Dimensions (W x D x H) | 434mm x 308mm x 121 mm |
| Weight | 6.8 kg |
| Packed Weight | 8.1 kg |
What’s in the Box?
- 2 x 3010i Bookshelf Speakers
- 2 x foam bungs
- 2 x speaker grilles
- User manual
- Handling gloves
- 8 x rubber speaker grips
Specifications Dimensions
| Dimensions (W x H x D) | 150 x 253 x 252 mm |
|---|---|
| Weight Each | 4.1 kg |
General
| Enclosure type | 2-way reflex |
|---|---|
| Bass unit | 100 mm (4″) |
| Treble unit | 22 mm (0.88″) |
| Frequency response (+3 dB, -6 dB) | 65 Hz – 30 kHz |
| Average impedance | 6 Ω |
| Minimum impedance | 4 Ω |
| Sensitivity (2.83 V @ 1 m) | 86 dB |
| Stereo amplifier power | 15 – 75 Watts |
| AV receiver (2 ch. driven) | 50 – 125 Watts |
| Cross-over frequency | 2.6 kHz |
| Effective volume | 4.0 l (244 cu. inch) |
