DALI E-12F Subwoofer, Satin Black

Full Description

The launch of the DALI SUB E-12 F marks a new stage of what is possible at this level of subwoofers. The E-12 F subwoofer by DALI features a 12-inch woofer, capable of moving plenty of air with power and precision. The cone is made from pure aluminium for maximum stiffness and a becoming exterior. Furthermore, the heavy magnet system wields a massive 4-layer, long-stroke voice coil. All in all, the heavy-duty abilities of this ‘motor system’ ensure that the woofer always follows the signal from the amplifier.

At the heart of this subwoofer is the 170W RMS Class D amplifier with a highly linear response. Embracing a classic DALI trademark, it simply acts as a total low frequency extension of your AV system. The result is a powerful, well-balanced bass reproduction and flawless integration with your speakers. In addition, the integrated limiter helps protecting your subwoofer against overloading.

The back plate of SUB E-12F features controls for volume adjustment, phase, and upper cut-off frequency, while the power on/off function works automatically via signal detection. And with the options for LFE or LINE inputs, this subwoofer easily accompanies any AV set up.

SUB E-12F is elevated from the floor by an aluminium base, while a down-firing bass port allows positioning directly against the wall. The front grille is mounted by magnets only – and when removed, the visual appearance changes from discreet to extravagant as the pure aluminium cone is revealed.

The DALI SUB-12F is recommended as compliment to the new ZENSOR series and is compatible with all DALI loudspeakers as the perfect completion of a DALI surround set up.



Frequency Range (+/-3 dB) [Hz]	28 – 190
Maximum SPL [dB]	112
Crossover Frequency [Hz]	40 – 120 Hz
Low Frequency Driver	1 x 12-inch long stroke Polymere Aluminimum
Enclosure Type	Bass Reflex
Bass Reflex Tuning Frequency [Hz]	36.0
Max. Amplifier Power Output [RMS watt]	220
Continous IEC Power Output [RMS watt]	170
Input Impedance [kOhm]	25
Connection input(s)	Mono line level (LFE)
Stereo line level (low pass filtered)	RCA
Recommended Placement	Floor in the corner
Recommended Distance From Wall	5cm
Functions	Crossover Frequency , Phase Switch
Maximum Power Consumption	250w
Max. Dimensions (Incl. Base And Grille)	H370 x W340 x D380mm
Weight	14.7kg
